C Series
For 1/4″, 3/8″ and 1/2″ hose I.D.
Low Pressure – reels are best applied in plant maintenance, service trucks and many other industrial functions where hose storage is a problem. Standard hose for air, water, and water based solutions. Other hoses available upon request. Medium Pressure – reels are required when higher pressures are involved for air, water, or heavier oils. Standard 1-wire braid hose furnished. High Pressure – reels are used exclusively where grease is being applied as in lube applications for off-road service or garage lube systems. Standard 2-wire braid hose furnished. *Available Powder Coat or (304) Stainless Steel. Reels shipped standard SF hose payout position. For ceiling mount add suffix SC.
Low Pressure – reels are best applied in plant maintenance, service trucks and many other industrial functions where hose storage is a problem. Standard hose for air, water, and water based solutions. Other hoses available upon request.
| Model Number | Operating Pressure | Hose I.D. | Hose Length | Shipping Weight |
| LC-300* | 1000 PSI | 3/8 IN | – | 46 |
| LC-340 | 300 | 3/8 | 40 FT | 49 |
| LC-350 | 300 | 3/8 | 50 | 50 |
| LC-370 | 300 | 3/8 | 70 | 54 |
| LC-500* | 1000 | 1/2 | – | 46 |
| LC-540 | 300 | 1/2 | 40 | 53 |
| LC-550 | 300 | 1/2 | 50 | 57 |
Medium Pressure – reels are required when higher pressures are involved for air, water, or heavier oils. Standard 1-wire braid hose furnished.
| Model Number | Operating Pressure | Hose I.D. | Hose Length | Shipping Weight |
| MC-300* | 4000 PSI | 3/8 IN | – | 47 |
| MC-340 | 2500 | 3/8 | 40 FT | 56 |
| MC-350 | 2500 | 3/8 | 50 | 58 |
| MC-500* | 4000 | 1/2 | – | 47 |
| MC-530 | 2500 | 1/2 | 30 | 56 |
| MC-540 | 2500 | 1/2 | 40 | 58 |
| MC-550 | 2500 | 1/2 | 50 | 61 |
High Pressure – reels are used exclusively where grease is being applied as in lube applications for off-road service or garage lube systems. Standard 2-wire braid hose furnished.
| Model Number | Operating Pressure | Hose I.D. | Hose Length | Shipping Weight |
| HC-200* | 8000 PSI | 1/4 IN | – | 46 |
| HC-240 | 5000 | 1/4 | 40 FT | 56 |
| HC-250 | 5000 | 1/4 | 50 | 59 |
| HC-300* | 8000 | 3/8 | – | 46 |
| HC-330 | 4000 | 3/8 | 30 | 56 |
| HC-340 | 4000 | 3/8 | 40 | 58 |
| HC-350 | 4000 | 3/8 | 50 | 62 |
* Hose not included
Heavy duty spring retractable hose reel ideal for air, water, motor oil, and grease. Available for 3/8″ & 1/2″ ID up to 70′ length.
