Description: Food and Beverage Transfer Hose
Tube: PVC
Reinforcement: 3 Polyester Spirals
Cover: PVC Clear
Temp. Range: +25 to +150F / -5 to +65C *
Applications: Food and Beverage Transfer, General Industrial, Water Main and Water Feed Hoses, Air, Pneumatic Applications and Light Vacuum.
| Dash | ID | OD | Working Pressure | Burst Pressure | Weight |
| Size | Inch | Inch | PSI | PSI | Per/ft |
| 03 | 3/16 | 300 | 900 | .036 | |
| 04 | 1/4 | 0.45 | 300 | 900 | .045 |
| 05 | 5/16 | 300 | 900 | .057 | |
| 06 | 3/8 | 0.59 | 300 | 900 | .09 |
| 08 | 1/2 | 0.75 | 300 | 900 | .138 |
| 12 | 3/4 | 1.02 | 250 | 750 | .165 |
| 16 | 1 | 1.30 | 150 | 450 | .219 |
| 20 | 1-1/4 | 1.61 | 100 | 300 | .450 |
| 24 | 1-1/2 | 1.89 | 87 | 260 | .64 |
| 32 | 2 | 75 | 250 | .95 |
Clearbraid hose is a common form of PVC hose that is used for its strength and temperature versatility. Reinforced by three polyester spirals, this hose is temperature resistant from 25F to 150F.
More About Reinforced, Clearbraid PVC Hose
Reinforced PVC hose is a highly versatile material that is widely used in many industries. Clearbraid hose is a common form of PVC hose that is used for its strength and temperature versatility. Reinforced by three polyester spirals, this hose is temperature resistant from 25F to 150F. Sometimes called Nylobraid hose, it is commonly found in food and beverage applications, water feeds and light vacuum lines.
- Clearbraid PVC Air and Water Hose
- FDA Listed
- Clear PVC with Braid Reinforcement 3/16″-2″
