Bison Fixed Height Stackable Pedestal | HD75-18 or HD75-316
Bison HD75 Fixed Height Stackable Pedestals provide a simple, low-profile way to build consistent elevation while maintaining uniform spacing between pavers or wood tiles. Integrated spacer tabs help support drainage and consistent alignment, and the stackable design allows added height where needed.
Models & Spacer Tab Options
- HD75-18: Fixed Height Stackable Pedestal with 1/8″ (3.2 mm) tabs
- HD75-316: Fixed Height Stackable Pedestal with 3/16″ (4.5 mm) tabs
Note: Bison recommends 3/16″ tabs when using Bison Wood Tiles.
Key Features
- Fixed height: 3/4″ (19 mm) per pedestal
- Stackable design: Stack up to 4
- Spacer tabs: Help provide uniform spacing and support drainage
- High load capacity: Supports up to 1250 lbs per pedestal (FoS: 3)
Specifications
| Specification | Value | Notes |
|---|---|---|
| Model Options | HD75-18 / HD75-316 | Tab size varies by model |
| Height | 3/4″ | 19 mm; stack up to 4 |
| Base Diameter | 5-7/8″ | 149 mm |
| Weight | 0.23 lbs | 0.10 kg |
| Weight Bearing Capacity | Supports 1250 lbs | 567 kg, FoS: 3, per pedestal |
Fastening System
No fastening hardware is specified for these stackable pedestals. Use with compatible pavers/tiles and follow manufacturer guidance and local building codes for layout, stacking limits, and installation requirements.
